| Model No. | | SB - 08 | SB - 08 |
| Power(electric, diesel, gasoline, liquefied petroleum gas) | | Electric | Electric |
| Driving mode (hand, pedestrian, stand-on, sit-down, unit-pick) | | Pedestrian | Pedestrian |
| Rated loading capacity Q | (kg) | 2000 | 2200 |
| Load centre distance C | mm | 600 | 600 |
| Front overhang distance X | mm | 963/1033 | 963/1033 |
| Track Y | mm | 1275/1335 | 1368 |
| Weights | | | |
| Weight (with accumulator) | kg | 450 | 520 |
| Axle load at full load Drive side/load side | kg | 850/1600 | 1082/1630 |
| Axle load without loading Drive side/load side | kg | 350/100 | 399/113 |
| Wheels | | | |
| Tyres (rubber wheels, high-performance elastomeric,Pneumatic wheels, polyurethane wheels) | | Polyurethane wheels | Polyurethane wheels |
| Tyre size, drive side | mm | 252 x 89 | 230 x 75 |
| Tyre size, load side | mm | 80 x 70 | 84 x 70 / 74 x 70 |
| Dimension of steering wheel | | 100 x 40 | 100 x 40 |
| Wheel numbers (X=driving wheel) Drive side/load side | | 1x +2/ 2/1x +2/ 4 | 1x +2 / 2/1x +2/ 4 |
| Wheel track (front)Drive side b10 | mm | 530 | 500 |
| Wheel track (back)load side b11 | mm | 380/525 | 380/525 |
| Dimension | | | |
| Lift height h3 | mm | 120 | 120 |
| Height of lever in middle position h14 | mm | 1050 | 1323 |
| Height of fork when being lowered h13 | mm | 82 | 85 / 75 |
| Overall length l1 | mm | 1785/1855 | 1851/1885 |
| Length of truck body l2 | mm | 635 | 665 |
| Width of truck body b1 | mm | 726 | 726 |
| Fork dimensions/e/l | mm | 60/160/1150 | 60/160/1150 |
| Lateral distance of fork b5 | mm | 540/685 | 540/685 |
| Distance from wheel base centre to ground m2 | mm | 22 | 25 |
| Right angle stacking aisle width, pallet800X1200(1200 placed along fork ) Ast | mm | 2295/2335 | 2305/2344 |
| Turning radius Wa | mm | 1630/1700 | 1640/1710 |
| Capability | | | |
| Driving speed full load/ no load | km/h | 5.0/5.2 | 5.8/6.0 |
| Lifting speed full load/ no load | mm/s | 22/30 | 19/35 |
| Lowering speed full load/ no load | mm/s | 31/23 | 30/27 |
| Climbing capacity full load/no load | % | 8/16 | 9/15 |
| Parking brake | | Electromagnetic brake | Electromagnetic brake |
| Motor | | | |
| Drive motor power kw | kW | 1.5 | 1.5 |
| Lift motor power | kW | 0.8 | 0.8 |
| Accumulator, U.K. BS standard, no | | 3VBS | 3VBS |
| Voltage of accumulator, capacity (discharge rate5 hours) | V/Ah | 24/165 | 24/210 |
| Accumulator weight (+/-5%) | kg | 160 | 185 |
| Battery dimension, length X width X height | mm | 455 x 196 x 570 | 645 x 196 x 570 |
| Others | | | |
| Driving and control methods | | FET Control | FET Control |
| Noise heard by the driver | dB(A) | <70 | <70 |
| Turning angle | o | <180 | <180 |
