Most Popular Model: Available in standard load capacities of 2500 kg, 3500 kg, and 5000 kg, ideal for diverse industrial applications.
Controlled Fork Lowering: Smooth and adjustable lowering speed operated conveniently by a foot pedal for enhanced precision and safety.
Ergonomic Handle Design: Features a rubber-wrapped handle for comfortable grip and effortless operation during extended use.
Easy Entry and Exit Rollers: Integrated entry and exit rollers allow for smoother pallet movement and reduced operator effort.
Overload Protection: Equipped with a high-quality overload valve to prevent excessive pressure and ensure long-lasting performance.
Extended Service Life: The adjustable pump cap design provides consistent performance and increases the overall service lifespan of the truck.
Customizable Sizes: Special fork width and length options can be manufactured on request to meet specific customer requirements.

Model No.		SB – 07	SB – 07	SB – 07
Capacity Q	kg	2500	3500	5000
Min. Fork Height h	mm	90	90	90
Max. Fork Height h1	mm	200	200	200
Steering Wheel	mm	180 x 50	180 x 50	180 x 50
Load Roller Single	mm	82 x 70	82 x 70	82 x 70
Load Roller Tandem	mm	82 x 70	82 x 70	82 x 70
*Size of Fork es**	mm	160 x 60	150 x 50	150 x 50
Width overall Forks B	mm	550 or 685	550 or 685	550 or 685
Fork Length I	mm	1150	1150	1150
NOTE : SPECIAL LENGTH & WIDTH IS AVAILABLE ON REQUEST
