Lifting Height: Efficiently lifts loads up to 800 mm or 1000 mm, ensuring ergonomic working height and reduced operator strain.
Load Capacity: Available in 800 kg and 1000 kg variants to suit different material handling needs.
Enhanced Stability: When raised, the truck automatically locks to the floor with extended outriggers and a long wheelbase, providing superior stability during lifting operations.
Smooth Manoeuvrability: Equipped with 200 mm diameter UHMW-PE steer wheels and UHMW-PE load rollers for effortless movement and precise control.
Low Maintenance Design: Fitted with heavy-duty ball bearings for reliable performance and reduced maintenance requirements.
Premium Sealing System: Uses high-quality seals and wipers to prevent leakage and extend service life.
Customizable Options: Special fork length, width, and wheel configurations can be customised as per specific application requirements.

Model No.		SB - 09	SB - 09
Capacity	kg	800	1000
Min. Fork Height	mm	90	90
Max. Fork Height	mm	800 / 1000	800 / 1000
*Size of fork es**	mm	160 x 50	160 x 50
Width of overall fork	mm	550	550
Length of fork	mm	1200	1200
Fork roller	mm	82 X 70	82 X 70
Big wheel	mm	200 x 50	150 x 50
NOTE : SPECIAL LENGTH & WIDTH IS AVAILABLE ON REQUEST
