Pit Mounted Lift Table
The PE-80 Pit Mounted Lift Table is engineered to deliver smooth, efficient, and reliable vertical lifting for industrial material handling. Installed flush with the floor, it allows easy loading and unloading while offering a safe and ergonomic working platform. Designed to provide high-quality performance at an economical price, the system supports lifting capacities from 500 kg to 3000 kg and table lengths of up to 5000 mm. With multiple scissor mechanisms, the lift table can achieve impressive lifting heights ranging from 1200 mm to 14,000 mm. Operated through a motorized hydraulic pump or manual hand pump, it enables operators to lift, lower, move, and transfer heavy materials seamlessly between floors, vehicles, and machinery—making it an ideal choice for demanding industrial environments.
Key Features
- Powered hydraulic lifting platform for efficient vertical movement
- High-quality construction offering performance at economical prices
- Lifting capacity range: 500 kg to 3000 kg
- Table length available up to 5000 mm
- Multiple scissor arrangements allow lifting from 1200 mm to 14,000 mm
- Hydraulic cylinder applies force through scissor mechanisms for smooth elevation
- Operable via motorized pump or hand pump
- Enables lifting, lowering, moving, and transferring heavy loads with ease
- Suitable for material transfer between floors, vehicles, and machinery
- Delivers fast and smooth operational performance
Applications
- Lifting heavy materials
- Transporting heavy dies or industrial components
Table Specification
| Platform Size | 1000 mm x 800 mm up to 5000 mm x 2500 mm |
| Min. Close Height | 600 mm up to 1500 mm |
| Max. Lifted Height | 1200 mm up to 14000 mm |
| Clear Lift Available | 600 mm up to 12500 mm |
| Load Capacity | 500 to 3000 kgs. |
